Column Mapping Freemium

Column Mapping tells QTO how to read each row of your catalog file (Excel, JSON, or CSV). For every internal QTO field — code, description, uom, prices, hierarchy levels — you supply a mapping value that QTO evaluates against the row to produce the final value. Mapping values range from a bare column name to a string template that combines multiple columns, all the way to a math expression that computes a number on the fly.

When you see this dialog

The Column Mapping editor opens from the QTOSetup dialog when you connect a new catalog source. Two paths bring you here:

• Auto-detection covered everything — the mapping is saved silently, but you can re-open the editor from QTOSetup any time to refine it.
• Auto-detection missed a mandatory field — the editor opens automatically so you can fill in what auto-detect could not infer from the column headers (typically code, description, and uom).

The dialog shows one row per internal QTO field. Each row has a formula box, an "Insert column" dropdown that lists every header found in your source, and a live preview that re-renders as you type. The preview uses the first non-header data row of your file as the sample. Mapping changes are not committed until you click Save.

The four forms

QTO classifies every mapping value into one of four forms by inspecting its syntax:

#	Form	Triggered by	Example
0	Empty	Blank / whitespace-only field	(nothing typed)
1	Bare column name	No {, no ", no math operator	Codice
2	String template	Contains {…} placeholders and/or "…" quoted literals, no math operators outside quotes	{Capitolo}" | "{Voce}
3	Math expression	Contains + - * / or a function call outside any quoted literal	round({price_total} * 1.22, 2)

The classification is purely syntactic — QTO never tries to "guess" the form from context. If you type a math expression, you get a number; if you type a template, you get a string; if you type a bare name, you get a direct cell lookup.

Form 1 — Bare column name

The simplest mapping is a single source column header. QTO looks up the value of that column in the current row and returns it verbatim (trimmed of leading and trailing whitespace).

• The lookup is case-insensitive: codice and Codice resolve to the same column.
• If the column does not exist in the source, the mapping returns empty for every row. The live preview shows an empty result; ingestion silently records null.
• If the cell is empty for a specific row, that row's mapped value is empty.

Form 2 — Templates with placeholders and literals

Templates combine values from multiple columns with fixed text. Two building blocks make up every template:

• Placeholders — {ColumnName} is replaced with the value of ColumnName in the current row, after the same trim-and-lookup logic as Form 1.
• Quoted literals — every character that is not part of a placeholder, including spaces and separators like |, /, -, must be wrapped in double quotes. Whitespace between placeholders and literals is ignored.

Template	Row data	Result
{Capitolo}" | "{Voce}	Capitolo = "Strutture", Voce = "Cls C25/30"	Strutture | Cls C25/30
{A}{B}	A = "foo", B = "bar"	foobar (placeholders glue without separator)
"He said ""hi"" to "{Name}	Name = "Sandro"	He said "hi" to Sandro (CSV-style "" → ")

Empty placeholder cleanup

When a {Placeholder} resolves to empty for a given row, QTO drops the placeholder and one adjacent separator-only literal (a quoted literal whose content is only spaces, pipes, slashes, or dashes). Then it collapses runs of repeated separators to one and trims leading or trailing separators. If the result is empty, the mapping returns null.

Template	Row data	Result
{Capitolo}" | "{Voce}" | "{Articolo}	all three columns populated	Strutture | Cls C25/30 | 001
	Voce empty, others populated	Strutture | 001 (one " | " dropped along with the empty placeholder)
{A}" | "{B}	both A and B empty	null (empty result)

Form 3 — Math expressions

A mapping value becomes a math expression as soon as it contains an arithmetic operator (+ - * /) or a function call (name() outside any quoted literal. Each {ColumnName} placeholder is resolved to the parsed numeric value of that column in the current row, the expression is evaluated, and the result is rendered as a number.

Operators

Addition +, subtraction -, multiplication *, division /, parentheses for grouping, and unary minus for negation (-{x}). Standard precedence applies: * and / bind tighter than + and -, parentheses override.

Functions

Function names are matched case-insensitively (ROUND, Round, round all work).

Function	Arity	Behavior
round(x)	1	Rounds to the nearest integer using banker's rounding (see note below).
round(x, n)	2	Rounds to n decimal digits. n must be an integer literal in [0, 15].
abs(x)	1	Absolute value.
sqrt(x)	1	Square root. Errors on negative input.
min(a, b, …)	≥ 2	Smallest of the arguments.
max(a, b, …)	≥ 2	Largest of the arguments.

Output format and decimal width

Math results are rendered with invariant-culture formatting (decimal point, no thousands separator). The number of decimal digits shown depends on the shape of your expression:

• Top-level round(x, n) — when the outermost call is round(value, n) with n an integer literal, the output is rendered with exactly n decimal digits, including trailing zeros. round({Price}, 2) on Price = "123.4" gives 123.40, not 123.4.
• Everything else — bare arithmetic, abs, sqrt, min, max, 1-arg round, or expressions where round is nested inside another operator (round({x}, 2) * 1.04) — the output uses the minimum digits needed to represent the value: 4 rather than 4.0, 123.4 rather than 123.40.

The rule is intentional: wrapping a math expression in round(…, n) is how you tell QTO the decimal width you want for the field.

Number formats in source cells

QTO tolerates an Italian-style decimal comma in source cells: a value like "1,5" in a numeric column is read as 1.5 in math expressions. This is convenient for catalogs exported from spreadsheets saved with Italian locale.

Common patterns

Goal	Mapping
Direct column copy	Codice
Build a description from chapter + item	{Capitolo}" | "{Voce}
Three-level hierarchy with auto-cleanup of empty middle level	{Capitolo}" / "{Voce}" / "{Articolo}
Price with VAT, two decimals	round({price_total} * 1.22, 2)
Safety surcharge added to base price	round({price_total} + {price_safety}, 2)
Hourly cost as max of two columns	round(max({labor_internal}, {labor_external}), 2)
Sign-flip a stored discount	-{discount}

Live preview and color coding

The preview cell next to each mapping row re-renders on every keystroke. The color tells you the state of the result:

Color	Meaning
Gray	Valid result. Long strings are truncated to about 120 characters in the preview, but the full value is saved.
Orange	Empty result for the current sample row. The mapping itself is syntactically valid — your sample row just happens to have empty values for the referenced columns.
Red	Error. Hover for the full message in the tooltip. See "Troubleshooting" below for common causes.

The preview is purely visual — nothing is committed until you click Save. Validation runs again on save: mandatory fields must have a non-empty mapping, and templates or math expressions that reference unknown columns are flagged before the dialog closes.

Auto-detection

When you first connect a new catalog source, QTO scans the source's column headers and tries to fill in each internal field with a bare column-name mapping. Matching is case-insensitive and treats underscores and spaces as equivalent (so super_chapter and Super Chapter both match the super_chapter field).

The recognized header aliases include both English and Italian variants for the mandatory fields (code, description, description_short, uom), all six price fields, and the three hierarchy levels (super_chapter, chapter, sub_chapter). Auto-detection only produces bare-name mappings — templates and math expressions are always manual.

If every mandatory field is auto-detected, the mapping is saved silently and you can move on. If any mandatory field fails to auto-detect, the editor opens so you can complete the mapping.

Troubleshooting

"Column 'X' not found in source row" in red

A placeholder {X} references a column header that does not exist in the source file. Check spelling against the "Insert column" dropdown, which lists every header QTO actually sees. The lookup is case-insensitive, so capitalization is not the issue.

"Column 'X' value 'abc' is not a number" in red

A math expression placeholder resolved to a non-numeric value. Either the cell genuinely contains text (in which case math is not the right form for this field — use a template instead) or the formatting prevents parsing. Italian decimal commas are accepted (1,5 → 1.5).

"Division by zero" in red

The denominator in a math expression evaluated to zero for the sample row. Either guard against it in the formula (no built-in if yet — check your source data) or revisit which column you are dividing by.

round shows fewer decimals than I expect

Trailing zeros are only preserved when round(x, n) is the top-level call of your math expression. round({x}, 2) * 1 and {x} + 0 use the minimum-digits format. Wrap the whole expression in round(…, n) as the outermost call to lock in the decimal width.

round(2.5) returns 2 — is this a bug?

No, that is banker's rounding (round half to even). Values exactly halfway between two integers go to the nearest even one. The behavior is consistent across the whole formula engine and matches the default of most programming languages. See the "Banker's rounding" note above for details.

"Mandatory field unmapped" warning blocks Save

The four mandatory fields are code, description, description_short, and uom. Each must have a non-empty mapping before the dialog will close. Use the "Insert column" dropdown to populate them.

See also

Last updated 2026-05-26 • Applies to v0.9+
